1.4.4.3.1.  Entering licenses... (License Server)

[Note]Note

Before you enter licenses, please cancel all running PARTsolutions applications!

If you install the license from a separate license server, then normally there is no PARTsolutions installation available. Since you need PARTadmin, this module has also been installed in the course of the installation routine.

In both cases call up PARTadmin via start menu:

Windows-Start menu -> CADENAS License Server -> Licenseserver

PARTadmin -> category FLM server -> tabbed page Licenses -> Add file...

The license administration will add the file in the correct directory automatically.

Then please do not forget to save .

Finish PARTadmin.

The Licensing is finished now.

[Note]Note

Background information:

In the installation path of the CADENAS License Server (default path "C:\Program Files\PARTsolutions Licenseserver") you can find the file start.env.

Please note!

Although the environment variables of the license server have the same name as in the PARTsolutions installation, they refer to different directories!

[ENVIRONS]
CADENAS=%DirOfThisFile%
CADENAS_SETUP=C:\ProgramData\PARTsolutions Licenseserver\setup
CADENAS_DEFAULTUSER=$CADENAS_SETUP\user\default_user
CADENAS_SITESETUP=C:\ProgramData\PARTsolutions Licenseserver\sitesetup
CADENAS_USER=%UserAppData%\PARTsolutions Licenseserver\user
CADENAS_LICENSE=$CADENAS_SITESETUP\lic
CADENAS_POOL=C:\ProgramData\PARTsolutions Licenseserver\pool
CADENAS_DATA=C:\ProgramData\PARTsolutions Licenseserver\data

The imported license is located on the CADENAS License Server under C:\ProgramData\PARTsolutions Licenseserver\sitesetup\lic\keys. Do not copy licenses manually, but always use the user interface as shown above.

Storage location of node-locked licenses in contrast is in the PARTsolutions installation under C:\ProgramData\PARTsolutions\sitesetup\lic\keys!

[Note]Note

Please also note the detailed advice under Section 1.4.4, “ Manage License server ”.
