4.25.7. Context menu

4.25.7.1. Set fields
4.25.7.2. Duplicate
4.25.7.3. Edit variant
4.25.7.4. Create variant
4.25.7.5. Assign ERP numbers / delete
4.25.7.6. Import project into database
4.25.7.7. Edit project table
4.25.7.7.1. Change standard descriptions according to project
4.25.7.7.2. Explicitly specify sorting order of variants for PARTdataManager table
4.25.7.7.3. Column sorting of geometry columns in PARTdataManager
4.25.7.7.4. Update structure table

You may call the context menu both in the directory tree and within the datasets as well.

[Note]Note

Depending on the initial situation, not all commands are visible and available in the context menus yet.

The following images clarify the different options:

  • Project level with connections

    Project level with connections

  • Project level without connections

    Project level without connections

  • Directory level with connections

    Directory level with connections

  • Directory level without connections

    Directory level without connections

The following list shows all possible context menu commands that are then explained in detail in the next section:

  • Set fields

    Edit the content of one or several selected fields.

  • Duplicate

    Duplicate the selected dataset. Afterwards, ERP fields (not geometry data) can be edited with Set fields for example.

  • Assign ERP numbers (overwrites an already existent ERP number)

  • Revoke ERP assignment (only selectable if a number has already been assigned)

    -> The dataset is now displayed in red.

  • Revoke ERP assignment and remove ERP number (only selectable if the number has already been assigned)

  • Import this project in database

  • Edit project table

[Note]Note

If no connection to the LinkDB exists, only the two last commands are available at project level.
